Victron Energy EasySolar-II 48V 5000VA 70A 50A MPPT 250 100 GX – PMP482507010 Online Sale

The Victron EasySolar-II GX integrates the following elements:

• A MultiPlus-II inverter charger
• A SmartSolar MPPT -Tr solar charge controller
• A GX device with a 2 x 16 character display

• These elements come prewired together inside a single unit. This greatly simplifies most installations, saving time and money.

  Display and wifi

  The display reads battery, inverter and solar charge controller parameters. The same parameters can be accessed with a smartphone or other wifi enabled device. In addition, wifi can be used to set up the system and to change settings.

  Solar charge controller

  The DC output of the SmartSolar MPPT is parallel wired with the DC connection of the MultiPlus-II inverter charger. The on off mechanism of the MultiPlus-II also controls the SmartSolar MPPT.

  GX device

  The integrated GX device includes:

  • A VE.Can interface. This can be used to connect to Victron VE.Can devices (e.g. VE.Can MPPTs), or the port can be reconfigured via the Remote Console for use with a compatible CAN-bus Li-ion Battery
  • A USB port
  • A Ethernet port
  • A VE.Direct port The GX device controls the MultiPlus-II and the SmartSolar MPPT with respectively a VE.Bus and a VE.Direct connection.

  • Brand		Victron Energy
    Manufacturer Part Number		PMP482507010
    GTIN		8719076049333
    Voltage		48V
    Cont. Output Power at 25°C		5000VA
    Peak Power		9000W
    Output AC Voltage		230V
    Transfer Switch		50A
    Max. AC Input Current		50A
    Max. Battery Charge Current		70A
    Protection Category		IP21
    Efficiency		96%
    Bluetooth Compatible		Yes
    Dimensions		H604 x W323 x D253mm
    Weight		38.6Kg
    Warranty		5 Years
