Powercube series products with its modular design concept, enables the highest flexibility both for rack mounted and container based constructions, giving the flexibilities for customer to deploy the system. Configurable from units of 5 – 12 modules per system, the system can supply 240 – 864V for high Voltage applications.

Product features

• -Modular and Scalable
•         5 – 12 modules per rack and up to 6 racks in series
• -Flexible BMS voltage range
•         From 240VDC to 864VDC
• -LiFePO4 technology
•         For safety and long cycle life
• -High System Safety
•         BMS has charge, current and temperature protection
• -Flexible configuration options
•         Rack mounted or container-based systems

• Each Battery module comes with 1 x Communication Cable and 1 x Orange Power Cable

  NB. Please note:



  A BMS unit and external cable kit is required for each individual stack of batteries.



  A minimum of 5x battery modules is required for BMS operation.



  For installations with two BMS units and more an MBMS is required.







  You can register the Pylon Powercube for an additional 3 years of manufacturer warranty for free. Go to http: www.pylontech.com.cn service support and complete the information in the sign up battery page.



  Supplier Part No: H48074NA01V00101

  Weight: 30 kg

  Battery Type: Lithium Ion

  Nominal Energy: 3552 Wh

  Depth of discharge: 90.00 %

  Voltage: 48 V

  Continuous Discharge Rate (Normal Use): 1776 W

  Maximum Discharge Rate (5 Minutes): 3552 W

  Surge Discharge Rate (15 Seconds): 3552 W

  Maximum Charge Rate (5 Minutes): 3552 W



  • Data Sheet Powercube H2
  • Title	Default Title
